압력방폭판넬

> 제품소개 > 압력방폭판넬

  • 인증번호 : 13-GA2BO-0589X (인증기관 : 한국가스안전공사)
  • 정격용량 : Normal Power : AC 220V
  • Ups Power : AC 115V (60Hz)
  • Protection Gas : Air
  • Purge System Type : Auto

No. SYMBOL DESCRIPTION
1 6000 SERIES AIR PURGE SYSTEM
2 EPV 6000 VENT
3 RV RELIEF VALVE

  • 인증번호 : 10-GA2BO-0190 (인증기관 : 한국가스안전공사)
  • 정격용량 : 220V 이하 50/60Hz
  • Protection Gas : Air
  • Purge System Type : Manu

No. SYMBOL DESCRIPTION
1 MV1~3 NEEDLE VALVE
2 MV4 BALL VALVE
3 FI-1,2 FLOW METER
4 AFR FILTER REGULATOR
5 AR1,2 AIR REGULATOR
6 RV RELIEF VALVE
7 PSL PRESSURE SWITCH
8 PDG PRESSURE GAUGE

  • 인증번호 : 12-GA2BO-0530 (인증기관 : 한국가스안전공사)
  • 정격용량 : AC115/220V 20/30A 60Hz
  • Protection Gas : Air
  • Purge System Type : Manu

No. SYMBOL DESCRIPTION
1 MV1 RAPID CONTROL VALVE
2 MV2 ENCLOSURE PRESS
CONTROL VALVE
3 AR REGULATOR
4 PDG PRESSURE GAUGE
5 MV3 BALL VALVE
6 FI-1 FLOW METER
7 RV RELIEF VALVE
8 PSL PRESSURE SWITCH
